Brixwell Adjustable Glass-to-Glass Mount Shower Door Pivot Hinge, Solid Forged Brass, Polished Brass Finish, Overhead Fixed Transom, 3/8" and 1/2" Glass Thickness, 3-1/4" End to End Hole Spacing

The Brixwell Adjustable Glass-to-Glass Mount Shower Door Pivot Hinge in Polished Brass finish is designed for frameless shower enclosures requiring a connection to overhead fixed transoms. Made from solid forged brass with precision-machined stainless steel internal components, this hinge ensures strength, reliability, and smooth performance in shower hardware, glass hardware, and door hardware applications. It features dual precision wound stainless steel return springs that deliver self-centering 0 degree return and self-closing from a 25 degree door angle. Its adjustable design allows installers to set the closing position up to 90 degree in or out after installation. Using the included 3mm hex wrench, screws can be loosened, the door repositioned, and then re-tightened to achieve precise alignment. The non-mouse ear design simplifies adjustment while maintaining a clean frameless appearance. This hinge is compatible with 3/8" (10mm) and 1/2" (12mm) tempered glass, requiring fabrication cutouts for proper fit. Each hinge is rated at 40 lbs, with two hinges supporting shower doors up to 120 lbs and a maximum width of 36". For weight guidance, 3/8" glass is 5.05 lbs/sf while 1/2" glass is 6.40 lbs/sf. Dimensional specifications include glass edge to hole spacing of 1-13/16" (top and bottom) and end to end hole spacing of 3-1/4". The square corner and edge profile deliver a modern look in frameless hinge applications. Hardware includes stainless steel hex clamping screws, crosshead screws, and a hex wrench in matching finish. This hinge integrates into pivot hinge, glass mount, and frameless hinge systems, making it suitable for both residential and commercial shower projects.

• SOLID FORGED BRASS: Constructed from solid forged brass with polished brass finish, offering robust hinge body that coordinates with frameless hinge, glass mount, and shower hardware for modern installations.
• PRECISE DIMENSIONS: Glass edge to hole spacing of 1-13/16" (top and bottom) and end to end spacing of 3-1/4", with square corners and edges to ensure accurate fabrication and installation in frameless hinge setups.
• SELF-CENTERING ACTION: Features dual stainless steel return springs for self-centering 0 degree return with self-closing from 25 degree door angle, supporting consistent performance in pivot hinge and frameless hinge designs.
• DOOR CAPACITY RATINGS: Each hinge supports 40 lbs; two hinges carry up to 120 lbs with maximum width of 36", providing stability and reliability for shower doors built with 3/8" or 1/2" tempered glass panels.
• ADJUSTABLE FUNCTION: Closing position can be set up to 90 degree in or out after installation, using included 3mm hex wrench to loosen screws, align the door, and re-tighten, ensuring accurate fit in shower hardware systems.
• INSTALLATION HARDWARE: Includes matching stainless steel clamping screws, crosshead screws, and hex wrench, blending with polished brass finish while supporting pivot hinge, glass hinge, and shower hardware systems.
